Drag Box
BoxesOur drag boxes are designed with a twosided protective shield, making them the perfect solution when installing utility pipes in dry, self-supporting ground, this is ideal in areas where obstructions such as underground services are present.
With a front cutting edge which enables the ‘excavate and drag’ technique, our drag boxes provide safe and rapid means of pipe laying, enabling quicker installation. All of our drag boxes are easy to assemble and install on site, constructed with minimal components.
Standard Solution
Related applications
Related Products
Give us a call
For all project specific design and technical enquiries, please contact your local service team
Send us an email
If you want to talk to us about your project, send us an email and a brief outline of how we can help and we’ll be in touch
[email protected]Variation:
| Standard Mini Drag Box 3m x 2m | |
|---|---|
| Length x height (m) | 3 x 2 |
| Capacity (kN/m²) | 25 |
| Max trench depth (m) | 3.9 |
| Min & max trench widths (m) | 0.68 – 3.08 |
| Under strut clearance (m) | 1.01 – 1.2 |
| Length between struts (m) | 2.65 |
| Box weight (kg) | 970 – 1960 |
| Hogback struts available | No |
| Standard Midi Drag Box 4m x 2m | |
|---|---|
| Length x height (m) | 4 x 2 |
| Capacity (kN/m²) | 20 |
| Max trench depth (m) | 2.9 |
| Min & max trench widths (m) | 0.68 – 2.68 |
| Under strut clearance (m) | 1.01 – 1.2 |
| Length between struts (m) | 3.65 |
| Box weight (kg) | 970 – 1960 |
| Hogback struts available | No |
| Standard Maxi Drag Box 5m x 2m | |
|---|---|
| Length x height (m) | 5 x 2 |
| Capacity (kN/m²) | 20 |
| Max trench depth (m) | 2.9 |
| Min & max trench widths (m) | 0.71 – 2.71 |
| Under strut clearance (m) | 1.01 – 1.2 |
| Length between struts (m) | 3.65 |
| Box weight (kg) | 1480 – 2670 |
| Hogback struts available | No |
| Heavy Duty Drag Box 5m x 2.5m | |
|---|---|
| Length x height (m) | 5 x 2.5 |
| Capacity (kN/m²) | 35 |
| Max trench depth (m) | 3.9 |
| Min & max trench widths (m) | 0.81 – 2.66 |
| Under strut clearance (m) | 1.48 – 1.97 |
| Length between struts (m) | 3.73 |
| Box weight (kg) | 3761 – 7094 |
| Hogback struts available | Yes |
| Heavy Duty Drag Box 7m x 2m | |
|---|---|
| Length x height (m) | 7 x 2 |
| Capacity (kN/m²) | 34 |
| Max trench depth (m) | 3.9 |
| Min & max trench widths (m) | 0.94 – 2.79 |
| Under strut clearance (m) | 1.25 – 1.75 |
| Length between struts (m) | 6.35 |
| Box weight (kg) | 4341 – 5036 |
| Hogback struts available | Yes |
| Heavy Duty High Clearance Drag Box 5.1m x 3.2m | |
|---|---|
| Length x height (m) | 5.1 x 3.2 |
| Capacity (kN/m²) | 25 |
| Max trench depth (m) | 4.9 |
| Min & max trench widths (m) | 1 – 5.3 |
| Under strut clearance (m) | 1.22 – 2.28 |
| Length between struts (m) | 4.5 |
| Box weight (kg) | 3846 – 9468 |
| Hogback struts available | No |
